Description
Ezviz CB1 Battery Operated Indoor Wi-Fi Camera
- 1080p Resolution
- IR Night Vision Up to 5 m (16 ft)
- Smart Human Motion Detection
- Up to 40 Days of Battery Life¹ (1,600 mAh Rechargeable Battery)
- Install with Magnetic Base
- Two-Way Talk
- Sleep Mode for Privacy Protection
- Smart Integration with Google Assistant & Amazon Alexa²
- Supports MicroSD Card (Up to 512 GB) & EZVIZ CloudPlay Storage
Dual video storage options
Safely store important moments or cute memories on a large local storage card, or by subscribing to the EZVIZ CloudPlay.
Hands-free control
With integration to your voice assistants, you can pull up the video feed by simply saying “Alexa” or “Hey Google.”
We do our best to protect data and privacy.
We respect your home as your special space, and we build complex security systems to safeguard your device and data. You can also enable Sleep Mode on the CB1 when needed, which stops all camera activities.
A versatile choice for simpler protection
Specifications
| Specifications | |
|---|---|
| Model | CS-CB1-R100-1K2WF |
| Camera | |
| Image Sensor | 1/3” 2-Megapixel Progressive Scan CMOS Sensor |
| Shutter Speed | Self-Adaptive Shutter |
| Lens | 2.8mm@ F2.2 Viewing angle: 113° (Diagonal), 90° (Horizontal), 50° (Vertical) |
| Minimum Illumination | 0.1 Lux |
| Lens Mount | M12 |
| Day & Night | IR-cut Filter with Auto Switch |
| DNR | 3D DNR |
| Night Vision | Up to 5 m / 16 ft |
| Function | |
| Smart Alarm | Supports smart human motion detection. |
| Customized Alert Area | Supports |
| Two-way Talk | Supports |
| Storage | |
| Local Storage | Supports microSD card (Up to 512 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay storage (subscription required) |
| Video & Audio | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | 15fps. Self-Adaptive during Network Transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Full HD; Hi-Def; Standard |
| Audio Bit Rate | Self-Adaptive |
| Max. Bitrate | 1 Mbps |
| Network | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Wired Network | Does not support. |
| Minimum Network Requirement | 2 Mbps |
| General | |
| Operating Conditions | -10°C to 45°C (14°F to 113 °F), Humidity 95% or Less (Non-condensing) |
| Power Supply | DC 5V/1A (Purchased Separately) |
| Battery Capacity | 1600 mA |
| Dimensions | 67 × 63 × 105 mm (2.64 × 2.48 × 4.13 inch) |
| Packaging Dimensions | 91.5 × 87.5 × 149 mm (3.60 × 3.44 × 5.87 inch) |
| Bare Weight | 135 g (4.76 oz) |
| In the box | |
| In the box | – CB1 Camera |
| – Power Cable | |
| – Foam Sticker | |
| – Mounting Metal Plate | |
| – Regulatory Information | |
| – Quick Start Guide | |
| Certifications | |
| Certifications | CE / WEEE / RoHS / REACH / UL |
