HiLook 2MP 20m Indoor Fixed Turret Camera

Interface

• Video Output1 HD analog output.
• Switch Button: TVI/AHD/CVI/CVBS.

• Menu

• Day/Night Model IR cut filter.
• DWDR (Digital Wide Dynamic Range) Support.
• Language: English
• Functions: Brightness, Sharpness, DNR, Mirror, Smart IR
• Backlight Compensation Support

• Camera

• Image Sensor2 MP CMOS image sensor
• Signal System: PAL/NTSC
• Frame Rate

  PAL: 1080p@25fps

  NTSC: 1080p@30fps

• Resolution1920 (H) × 1080 (V)
• Shutter Time1/25 (1/30) s to 1/50,000 s
• Min. Illumination0.02 Lux@ (F2.0, AGC ON), 0 Lux with IR
• Lens2.8 mm, 3.6 mm
• Horizontal Field of View

  2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°

  3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°

• Lens MountM12
• Day & Night IR cut filter.
• Synchronization Internal synchronization
• Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°

• General

• Power Supply12 VDC ± 15%
• Power Consumption Max. 2.1 W
• Material Plastic
• IR Range Up to 20 m
• Dimensions Ø 85.4 mm × 76.12 mm (Ø 3.38″ × 2.67″)
• Weight130 g (0.29 lb.)
• Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
